U6-LR

📡 Ubiquiti UniFi 6 LR (U6-LR) – Technical Information

U6-LR, Wi-Fi 6 (802.11ax)a technology that supports and offers long rangeaccess point'tir. Long range ve high performanceThis model is ideal for installations that require effective wireless network distribution, especially in large areas.

📶 Wireless Features

• Wi-Fi Standard:

  • 802.11a/b/g/n/ac/ax (Wi-Fi 6)

• Frequency Band:

  • 2.4 GHz ve 5 GHz (dual-band)

• Maximum Wireless Speed:

  • 2.4 GHz600 Mbps (2x2 MU-MIMO)

  • 5 GHz2400 Mbps (4x4 MU-MIMO & OFDMA)

  • Toplam: 3000 Mbps (3 Gbps)

• Antenna Gain:

  • 2.4 GHz5.4 dBi

  • 5 GHz6.5 dBi

• Channel Width:

  • 20, 40, 80 MHz @ 2.4 GHz

  • 20, 40, 80, 160 MHz @ 5 GHz

• MU-MIMO and OFDMAIt enables more devices to connect simultaneously with support.

🔌 Hardware Specifications

• Ethernet Port:

  • 1 x 10/100/1000 Mbps RJ45Power over Ethernet In

• PoE Support:

  • 802.3af PoE (48V)works with

  • PoE adapter in the boxyoktur)

• Maximum Power Consumption:13W

🛠️ Physical Properties

• Boyutlar:220 x 220 x 45 mm

• Ağırlık:500 g (cihaz) 700 g(with assembly set)

• MontajSuitable for ceiling and wall mounting.

  • Assembly kits are included in the box.

• IP Protection:Sadece Indoor useis suitable for

• Operating Temperature-30°C to +70°C Humidity: 5% – 95% non-condensing

🌐 Management and Software Features

• Management Platform:

  • UniFi Network ControllerCloud-based management support

  • Management with the UniFi mobile application

• Supported Features:

  • VLAN support

  • Guest Network & Captive Portal

  • Zero Handoff Roaming

  • Band steering, Quality of Service (QoS), Traffic Shaping

  • Support for DFS (Dynamic Frequency Selection) channels

  • RF analysis, management interface capable of analysis

📦 Box Contents

• UniFi 6 LR (U6-LR) AP

• Ceiling and wall mounting apparatus

• Screws and installation guide

• ⚠️ PoE adapter is not included.

🎯 Usage Scenarios

• Large offices and commercial spaces

• Schools, hospitalssuch intensive usage areas

• Large meeting rooms, event areas

• Retail stores ve kafeler
