The ZTE F680 is a GPON ONT (Optical Network Terminal) device primarily used in FTTH (Fiber to the Home) infrastructures. It combines modem, router, VoIP, and WiFi features in a single device.
| 📍 Feature | 📊 Details |
|---|---|
| 📶 GPON Interface (Optical Input) | 1 × GPON (SC/APC connector) |
| 🔁 Data Rate (GPON) | Downstream: 2,488 Gbps Upstream: 1,244 Gbps |
| 🌐 Ethernet Ports | 4 × Gigabit Ethernet (RJ‑45) |
| 📞 Phone Ports (VoIP) | 2 × FXS (RJ‑11) |
| 📡 WiFi Bands | 2.4 GHz & 5 GHz — Dual Band |
| 📶 WiFi Structure | 2.4 GHz: 2×2 MIMO 5 GHz: 4×4 MIMO / 802.11ac |
| 🔌 USB Port | 1 × USB 2.0 (Storage, 3G/4G modem, printer, etc.) |
| 🔐 Security & Encryption | WPA / WPA2 encryption, MAC filtering, VPN support |
| 🌡 Working Conditions | 0 °C – 40 °C / Humidity 5% – 95% (non-condensing) |
| ⚡ Power Consumption / Supply | Power supply with 12 V DC adapter – typically < 15 W consumption |
| 🧩 Compatibility / Standards | ITU‑T G.984 / G.988 optical standards |
| 🛠 Management & Protocols | Web GUI, OMCI, TR-069 |
| 📦 Physical Structure | Wall mounting and desktop usage support |
🌐 Bothmodem + router + WiFi + phoneoffers its functions on a single device
📱 Dual-band WiFiThanks to it, it supports 2.4 GHz and 5 GHz devices simultaneously.
📞 VoIP supportand provides analog telephone services over the internet.
📂 USB portConnection with external storage or 3G/4G modem is possible.
🛡 Advanced network featuresNAT, VLAN, QoS, IGMP snooping, IPv4/IPv6 support
🔧 OMCI / TR-069with the support of the service provider, remote management convenience
