USW-24-POE, Ubiquiti Networks' UniFi Switch seriesa 24-portManaged switchIt is a (manageable key) device. This model,PoE (Power over Ethernet)It provides both power and data transmission to devices by offering support.UniFi ControllerThis switch, fully compatible with, especiallyon internal networks, on security cameras ve Wi-Fi access pointsIt is ideal for meeting PoE requirements.
Total Port Count:24 x 10/100/1000 Mbps Ethernet port
PoE Ports:
24 x 10/100/1000 Mbps Ethernet port(All ports support PoE+)
PoE+ (802.3at) çıkışı: 250W total PoE power
It can power PoE-supported devices (e.g.,UniFi AP, IP cameras)
SFP Ports:2 x 1G SFP port(For fiber connections)
PoE Power:250W (Toplam)
Switch Type:Layer 2+ Managed Switch
Ethernet Speed:Gigabit Ethernet(10/100/1000 Mbps)
Yönetim:
UniFi ControllerManagement with software
Web UI, mobile applicationwith user-friendly management interface
Max. Power Consumption:400W
Input Power:100-240V AC, 50-60Hz
Boyutlar:44.5 x 26.5 x 4.4 cm(W x D x H)
Ağırlık:3.75 kg
Montaj:19-inch rackcan be used with the assembly
Port Gun and VLAN:Port gunwith port-based access controlVLAN (Virtual Local Area Network) desteği
QoS (Quality of Service):Layer 2 QoSwith priority data transmission
Advanced Security:
802.1X port security
MAC address-based access control
Management Platform:
UniFi Network ControllerEasy management over
Web interface ve mobile applicationaccessible via
Real-timenetwork monitoring and performance reports
Software Features:
VLAN, LAG (Link Aggregation), STP (Spanning Tree Protocol)
Link Layer Discovery Protocol (LLDP)
Port mirroring, PoE schedulingsuch advanced features
Large offices, corporate networks ve industrial facilities
IP cameras, Wi-Fi access points ve VoIP phonesfor power and data transmission
Security systems, IoT devices ve video conferencing systemsNetwork structures that provide PoE support in applications such as
USW-24-POE Switch
Rack Mounting Kits
Power Cable
User manual
