EdgeSwitch ES-16-150W, Ubiquiti'sEdgeMAXA manageable, PoE-supported one belonging to the seriesGigabit switchIt is a model. BothLayer 2and also limitedLayer 3It offers routing features and is particularly preferred in medium-scale network solutions.
| Model | ES-16-150W |
| Seri | EdgeMAX / EdgeSwitch |
| Type of Management | Manageable (Web GUI, CLI, SNMP) |
| Layer Support | Layer 2 (full) + Layer 3 (static routing) |
| RJ45 Gigabit Ethernet | 16 x 10/100/1000 Mbps | PoE supported |
| SFP (1G) Fiber Ports | 2 | Uplink/fiber connection for |
| PoE Standard | 802.3af / 802.3at and 24V Passive |
| Total PoE Power | 150 W |
| Number of PoE Ports | 16 port |
| Switching Capacity | 36 Gbps |
| İletim Hızı | 26.78 Mpps |
| MAC Address Table | 8000 entries |
| Jumbo Frame | 9,216 bytes |
| Buffer Memory | 1 MB |
YönetimWeb GUI, CLI (Telnet, SSH), SNMP
VLAN Support
QoS (Quality of Service)
STP, RSTP, MSTP
Link Aggregation (LACP)
Port Mirroring
DHCP Snooping, IGMP Snooping
ACL (Access Control List)
Static Routing (Layer 3)
| Boyutlar | 443 x 221 x 43 mm |
| Ağırlık | 3.9 kg |
| Montaj | 1U Rack Mount |
| Soğutma | Active (with fan) |
| Power Input | 100-240V AC, 50/60 Hz |
| Max. Power Consumption | 150 W |
| Operating Temperature | -5°C to +40°C |
| Ethernet Port | 16 x GbE PoE/PoE+/24V Passive |
| SFP Uplink Port | 2 x 1G SFP |
| Total PoE Power | 150 W |
| Switching Capacity | 36 Gbps |
| İletim Hızı | 26.78 Mpps |
| Management Interface | Web GUI, CLI, SNMP |
| Montaj | 1U Rackmount |
| Fan | Var |
IP camera systems (direct connection with PoE)
Wireless AP infrastructures (UniFi, AirMax)
Corporate network backbone and access layer
Work environments requiring VLAN and QoS
