U6-PRO

Ubiquiti UniFi U6-PRO , a high-performanceWi-Fi 6 (802.11ax)It is an access point. It is specifically designed to meet high bandwidth and low latency requirements in indoor environments with heavy user traffic.

📡 Wireless Features

• Frequency Bands: 2.4 GHz and 5 GHz (dual band)

• MIMO Structure:

  • 2.4 GHz: 2x2 MU-MIMO

  • 5 GHz: 4x4 MU-MIMO

• Maximum Data Rates:

  • 2.4 GHz: 573.5 Mbps

  • 5 GHz: 4.8 Gbps

• Total Theoretical Bandwidth: 5.3 Gbps

• Channel Width Support: 20/40/80/160 MHz

• Antenna Gain:

  • 2.4 GHz: 4 dBi

  • 5 GHz: 6 dBi

• Maximum Transmission Power:

  • 2.4 GHz: 22 dBm

  • 5 GHz: 26 dBm

• Maximum Client Count: 300+ simultaneous connections

⚙️ Hardware and Physical Features

• Ethernet Port: 1 unit 1 Gbps RJ45

• Power Input: 802.3at PoE+ or 48V Passive PoE (44–57V DC)

• Maximum Power Consumption: 13 W

• Boyutlar: Ø197 x 35 mm

• Ağırlık: Device: 580 g; With assembly: 720 g

• Operating Temperature: Between -30°C and +60°C

• Moisture Resistance: 5% – 95% (non-condensing)

• Protection Class: IP54 (resistant to dust and water splashes)

• Assembly Options: Ceiling and wall mounting (mounting kit included)

🛠️ Software and Management Features

• Management Interface: UniFi Network Application (version 6.1.56 and above)

• Supported Features:

  • VLAN assignment via RADIUS

  • Guest traffic isolation

  • Speed limit per user

  • Easy setup with Bluetooth 5.0

• Sertifikalar: CE, FCC, IC

🎯 Usage Scenarios

• Offices and Corporate Networks: It provides uninterrupted and fast connection in high-density user environments.

• Educational Institutions: It offers extensive coverage and high connection capacity in classrooms and amphitheaters.

• Hotel and Accommodation Facilities: It provides secure and fast internet access by isolating guest traffic.

• Retail Stores: It increases security by creating separate networks for customers and staff.
