CRS510-8XS-2XQ-IN

​MikroTik CRS510-8XS-2XQ-IN is a 100 Gigabit switch that offers high-speed and flexible connectivity options. It is specifically designed for data centers, service provider networks, and high-performance computing (HPC) environments.​

📦 General Features

• Model Code: CRS510-8XS-2XQ-IN

• İşlemci: Qualcomm Atheros QCA9531, 650 MHz, single-core

• Mimari: MIPSBE

• RAM: 128 MB

• Depolama: 32 MB Flash

• Operating System: RouterOS v7 (License Level 5)

• Switching Chipset: Marvell Prestera 98DX4310

• MTBF (Mean Time Between Failures): Approximately 200,000 hours @ 25°C

• Operating Temperature Range: -40°C to +70°C

🔌 Connection Points

• Fiber Connections:

  • 8 units of 25G SFP28 ports

  • 2 pieces of 100G QSFP28 ports

• Ethernet:

  • 1 unit of 10/100 Mbps RJ45 management port

• Console Port: RJ45 serial port​

⚡ Power and Cooling

• AC Inputs: 2 units (100–240V, hot-swap supported)

• DC Inputs: 3 pieces (DC jack, PoE-in, 2-pin terminal)

• PoE-in: 802.3bt standard (42.5–57V)

• Maximum Power Consumption: 45W (27W excluding additional equipment)

• Soğutma: Active cooling with 2 fans.

🛠️ Features and Functions

• VLAN, ACL, MLAG, Jumbo frame support

• Partial Layer 3 hardware acceleration

• Backward compatibility: Compatible with 1G, 10G, 25G, 40G devices.

• Emergency management through the console port.

• Uninterrupted operation with dual hot-swap power supply​

📐 Physical Properties

• Boyutlar: 320 x 185 x 44 mm

• Case Type: Desktop or rack mount compatible
