MikroTik CCR2216-1G-12XS-2XQ, is a high-performance router designed for data centers, service providers, and large-scale networks. This device stands out with its 100G connection support and powerful hardware features.
Product Code: CCR2216-1G-12XS-2XQ
İşlemci: Amazon Annapurna Labs AL73400, 16-core, 2.0 GHz, ARM 64-bit architecture
RAM: 16 GB DDR4
Depolama: 128 MB NAND Flash
M.2 Slots: 2 SATA3 supported M.2 2280 B+M keyed SSD slots (no capacity limitation)
Ethernet: 1 x 10/100/1000 Mbps RJ45 port
SFP28: 12 x 25G SFP28 port
QSFP28: 2 x 100G QSFP28 port
Supported speeds: 1x 100G, 2x 50G, 1x 50G, 1x 40G, 4x 25G, 4x 10G, 4x 1G
Unsupported speeds: 2x 40G
Switch Chipset: Marvell Prestera 98DX8525
CPU Connection: 4 x 25 Gbps connection line
RouterOS License: Level 6 (Only RouterOS v7 supported)
IPsec Hardware Acceleration: Mevcuttur
Boyutlar: 443 x 367 x 44 mm
Operating Temperature: -20°C to +60°C
Number of AC Inputs: 2 (100–240 V, 50–60 Hz)
Maximum Power Consumption: 128 W
Power Consumption Without Additional Devices: 80 W
Soğutma: 4 hot-swap supported fans
Power Supply: Dual redundant, hot-swap supported power supplies
CCR2216-1G-12XS-2XQ device
IEC power cable
Rack mounting ears
Cable management brackets
K-82 fixing set
Rack mounting rear support ears (2 pieces)
High Bandwidth: It provides high-speed data transmission with 100G QSFP28 and 25G SFP28 ports.
Advanced Processor: It offers high processing capacity with a 16-core 2.0 GHz processor.
Hardware-Based Routing: Routing performance increases with L3 hardware acceleration.
Redundant Power and Cooling: Uninterrupted operation capability with hot-swap supported power supplies and fans.
Expandable Storage: M.2 SATA slots provide additional storage options.
