CAMBIUM ePMP Force 300-25

📡 General Description

ePMP Force 300-25, Cambium Networks' high-performance and durable 5 GHz band operatingSubscriber Module (SM)That is, it is a subscriber device. Integrated high gain25 dBi parabolic antennaIt is ideal for long-distance, fixed wireless access (FWA) applications. It is fully compatible with ePMP 3000 series Access Point (AP) devices.

⚙️ Technical Specifications

• Model Name:ePMP Force 300-25

• Frequency Range:4910 – 5970 MHz (ROW and EU versions are available)

• Channel Width:20 / 40 / 80 MHz

• Maximum Data Rate (PHY):700+ Mbps

• MIMO:2x2 MIMO

• Modülasyon:BPSK - 256 QAM

• TDD Synchronization:GPS-assisted Cambium Time Sync

📶 Antenna Features

• Antenna Type:Integrated Parabolic Antenna

• Antenna Gain:25 dBi

• Coverage Angle:

  • Horizontal: 7°

  • Vertical: 7°

• Polarizasyon:Dual Slant (±45°)

🔌 Power and Connection

• Ethernet Port:1 × Gigabit Ethernet (10/100/1000 Mbps) RJ45

• PoE Input:Passive PoE, 30 V DC

• Power Consumption:Approximately 12 W

• PoE Adapter:Included in the box (varies by region)

🧱 Physical Properties

• Boyutlar:25.8 × 16.5 × 5.0 cm

• Ağırlık:Approximately 900 grams

• Protection Class: IP55

• Operating Temperature:-30°C to +60°C

• Wind Resistance:Durable up to 200 km/h

• Montaj:With pole or wall mounting bracket

🌐 Software & Management

• Yönetim:Web GUI, CLI, cnMaestro supported (cloud and on-premises)

• Güvenlik:WPA2 AES, Radius, MAC filtering

• QoS:Three levels for sound, video, and data

• Modlar:Bridge, NAT/Router supported

📦 Box Contents

• 1 × Force 300-25 SM device

• Assembly kit

• 30 V PoE adapter and power cable

• User manual

📍 Areas of Use

• Long-distance subscriber connections

• High bandwidth requiring enterprise and service provider applications

• Video surveillance and IoT applications

• ePMP 3000 AP with PtMP systems

✅ Advantages

• High antenna gain for long distance and high performance

• Durable and suitable for outdoor construction

• Easy installation and centralized management capability

• Advanced security and QoS features
