| Özellik | Değer |
|---|---|
| Frequency Range | 5.8 – 7.2 GHz |
| Gain | 33 dBi |
| 3 dB Beamwidth | ≈ 3.5° (typical) |
| VSWR | 1.4:1 (typical) |
| Empedans | 50 Ω |
| Input Power | 25 W |
| Cross Polarization | ≤ 32 dB (typical), ≤ 29 dB (maximum) |
| Inter-Port Isolation | ~45 dB (typical), ≥ 30 dB (minimum) |
| Front-Back Ratio (F/B) | 57.3 dB |
| Connection Type | 2 x N-Female |
| Özellik | Değer |
|---|---|
| Diameter / Size | 880 mm |
| Weight (including bracket) | 12.5 kg |
| Operating Temperature | Between -50°C and 70°C |
| Wind Load (Operating) | 130 mph |
| Wind Load (Survival) | 190 mph |
| Assembly Kit | Included / Direct Mounting |
| Pole Diameter | 25 – 60 mm |
| Additional Features | Precise Pan & Tilt Alignment |
Point to Point (PtP)high-speed data transmission
MIMOLong-range connections for supported systems
Applications requiring high performance in noisy environments
80 km üzerindeki LOS (Line of Sight) bağlantılar
