CAMBIUM PTP 550 INTEGRATED 5 GHz & LINE CORD

📡 General Description

Cambium PTP 550 Integrated 5 GHz, high capacity and reliablePoint-to-Point (PTP)It is a wireless radio system. It operates in the 5 GHz band and comes with an integrated antenna. It is designed for long-distance connections with fast data transmission, low latency, and advanced security features. It is ideal for industrial applications, service providers, and corporate networks.

⚙️ Basic Technical Specifications

• Model:PTP 550 Integrated 5 GHz

• Frequency Range:4900 – 6000 MHz

• Channel Width:5 / 10 / 20 / 40 / 80 MHz

• Maximum Data Rate:750+ Mbps (UDP)

• Modülasyon:OFDM, 256-QAM

• MIMO:2x2 MIMO

• TDD Synchronization:GPS assisted

📶 Antenna Features

• Antenna Type:Integrated parabolic antenna

• Antenna Gain:28 dBi (approximately)

• Coverage Angle:Approximately 6° (both horizontally and vertically)

🔌 Power and Connection

• Ethernet:1 × Gigabit Ethernet port (RJ45)

• PoE:48 V DC, compatible with IEEE 802.3af/at standard

• Power Consumption:Approximately 10 W

🧱 Physical Properties

• Boyutlar:Approximately 40 x 40 x 15 cm

• Ağırlık:~3.5 kg

• Protection Class: IP67

• Operating Temperature:-40°C to +60°C

• Wind Resistance:200 km/h

• Montaj:It is designed for direct or tower mounting.

🌐 Software & Management

• Yönetim:

  • Web GUI

  • CLI (SSH)

  • cnMaestro cloud/local management

• Güvenlik:

  • AES 128/256-bit encryption

  • Radius authentication

• QoS:Multiple traffic classification and prioritization

• Link Properties:Automatic power control, link budget optimization

📦 Box Contents

• 1 × PTP 550 Integrated 5 GHz radio

• Assembly kit

• Power cable and line cord (may vary by region)

• User manual

📍 Areas of Use

• Long-distance Point-to-Point wireless connections

• ISP and operator infrastructures

• Corporate campus connections

• Critical infrastructure and industrial automation

✅ Advantages

• High-capacity data transmission

• Durable outdoor design

• Easy installation and central management

• Advanced security and flexible structure
